Optical In-line-Amplifier (EDFA)

EDFA Amplifier Application: SDH Systems Long Haul Telecommunication System, Metro Access Networks Substitute for a RegeneratorFeature: Standard 19 inch 1U Rack Mounted High Gain Low Noise Figure, Low Power Consumption Wide Operating Wavelength RangeSpecifiation: ItemMin.Typ.Max.Operating Wavelength (nm)154015501560Signal Input Power (dBm)-25-20-8Signal Output Power (dBm)313Noise Figure @ 1550nm, -20dBm input (dB)4.85.5Input/Output Isolation (dB)30Pump Leakage to Input/Output (dBm)-30Input/Output Return Lose (dB)50Polarization Sensitivity (dB)0.3Input/Output InterfaceLC/PC FC/PC or Customer SpecifiedOperating Temperature (°C)0 50Storage Temperature (°C)-25 70Relative Humidity (Non Condensing)5% 95%Voltage90 240VAC or 36 60VDCDimension434mm (W) ´ 260 (D) ´ 44 (H)InstallationStandard 19” 1U Rack Mounted
